18 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05889-001 - RF/IF PCB
BOM Revision
Date Valid On
R473 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R474 5,6k Ohm 5% 0,1W 0805 Philips 2322 730 61562 40-35600-111 1
R475 3,3k Ohm 5% 0,1W 0805 Philips 2322 730 61332 40-33300-111 1
R476 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R477 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R478 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R479 3,3k Ohm 5% 0,1W 0805 Philips 2322 730 61332 40-33300-111 1
R480 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R481 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R482 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R483 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R484 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
T101 Txfr, RF Amp Protran 44-80263 44-80263 1
T102 Txfr, Rx I/P Protran 44-80261 44-80261 1
T103 Ind, Mixer 1 L.O. Buffer Sumida 44-70491 44-70491 1
T104 45MHz Roofing Filter Txfr Sumida 44-70493 44-70493 1
T105 Txfr, Mixer 2 Input KoilKraft 44-70486 44-70486 1
T106 Txfr, Exciter O/P Protran 44-80260 44-80260 1
T107 Txfr, 45MHz roofing filtr Codan 44-70451 44-70451 1
T108 Txfr, 45MHz roofing filtr Codan 44-70451 44-70451 1
T201 Ind, Buffer Output KoilKraft 44-70487 44-70487 1
T202 Ind, Buffer Output KoilKraft 44-70487 44-70487 1
T401 Balun Protran 44-80262 44-80262 1
V101 Transistor, NPN Si 18V 0,15A
4GHz SOT89
Philips BFQ18A BFQ18A 1
V102 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V103 JFET, Selected J310 01-01031 Avnet PST00-3289 PST00-3289 1
V104 JFET, Selected J310 01-01031 Avnet PST00-3289 PST00-3289 1
V105 JFET, Selected J310 01-01031 Avnet PST00-3289 PST00-3289 1
V106 JFET, Selected J310 01-01031 Avnet PST00-3289 PST00-3289 1
V107 Transistor, PNP Si SOT23 Philips BFT92 BFT92 1
V108 Transistor, PNP Si SOT23 Philips BFT92 BFT92 1
V109 MOSFET,N Chan Dual Gate
SOT143
Philips BF991 BF991 1
V201 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V202 Transistor, NPN Si SOT23 Philips BC848 BC848 1
Page 19 of 21
