Codan NGT 2010 RF User Manual

03 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05415-001 - PA PCB
BOM Revision
Date Valid On
C227 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C228 100u 25V Ax EL Cap Elna RB 48-21002-551 1
C229 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C230 100n 10% 50V X7R 1206
NiSn
Philips 12062R104K9BB- 46-51000-281 1
C231 470n 10% 63V PE Cap Philips 2222 370 18474 46-54700-521 1
C232 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C233 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
D200 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
D201 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D202 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
D203 Diode, Zener 15V 5% 0,2W
SOT23
Philips BZX84-C15 BZX84C15 1
D204 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D205 Diode, Si 400V 1A Fairchild 1N4004 1N4004 1
IC200 Reg, Voltage +5V 0,1A
SOIC8
National Semiconduct LM78L05ACM XB-07805-700 1
IC201 Amp, Operational Dual
SOIC8
National Semiconduct LM358M XA-00358-700 1
IC202 Amp, Oper Dual CMOS
SOIC8
National Semiconduct LMC662CM XA-00662-700 1
J200 Socket, Coax Mini Low Prof
Fixed
Taiko Denki TMP-J02X-A1 60-19390-002 1
K200 Relay, 1C 12V 16A 340
Ohm
Eberle 042901 62 0100 64-31125-234 1
L202 Ind, 1uH 10% 3028 Coilcraft 1008CS-102XKBC 43-80100-000 1
L205 Ind, PA DC feed or/wh/or Fetronics 44-70457 44-70457 1
P200 Header (P) 16way 2row Boxed Thomas & Betts 609-1627 60-00160-000 1
R200 47 Ohm 5% 0,125W 1206 Philips 2322 711 61479 40-14700-101 1
R201 47 Ohm 5% 0,125W 1206 Philips 2322 711 61479 40-14700-101 1
R202 56 Ohm 5% 0,125W 1206 Philips 2322 711 61569 40-15600-101 1
R203 330 Ohm 5% 0,125W 1206 Philips 2322 711 61331 40-23300-101 1
R204 330 Ohm 5% 0,125W 1206 Philips 2322 711 61331 40-23300-101 1
R205 Pot,100 Lin MG Trim SMD Bourns 3314 J-1-101 42-21004-000 1
R206 27 Ohm 5% 0,125W 1206 Philips 2322 711 61279 40-12700-101 1
R207 10 Ohm 5% 0,125W 1206 Philips 2322 711 61109 40-11000-101 1
R208 47k Ohm 5% 0,125W 1206 Philips 2322 711 61473 40-44700-101 1
