Codan NGT 2010 RF User Manual

03 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05415-001 - PA PCB
BOM Revision
Date Valid On
R238 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R239 5,6k Ohm 5% 0,125W 1206 Philips 2322 711 61562 40-35600-101 1
R240 Pot,10k Lin MG Trim SMD Bourns 3314 J-1-103 42-41004-000 1
R241 5,6k Ohm 5% 0,125W 1206 Philips 2322 711 61562 40-35600-101 1
R242 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R243 39k Ohm 2% 0,125W 1206 Philips 2322-711-41393 40-43900-102 1
R244 Pot,100k Lin MG Trim SMD Bourns 3314 J-1-104 42-51060-001 1
R245 27k Ohm 5% 0,125W 1206 Philips 2322 711 61273 40-42700-101 1
R246 47 Ohm 5% 0,125W 1206 Philips 2322 711 61479 40-14700-101 1
R247 47 Ohm 5% 0,125W 1206 Philips 2322 711 61479 40-14700-101 1
R248 47 Ohm 5% 0,125W 1206 Philips 2322 711 61479 40-14700-101 1
R249 47 Ohm 5% 0,125W 1206 Philips 2322 711 61479 40-14700-101 1
R250 330 Ohm 5% 0,125W 1206 Philips 2322 711 61331 40-23300-101 1
R251 330 Ohm 5% 0,125W 1206 Philips 2322 711 61331 40-23300-101 1
R252 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R253 Pot,10k Lin MG Trim SMD Bourns 3314 J-1-103 42-41004-000 1
R254 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R255 470 Ohm 5% 0,125W 1206 Philips 2322 711 61471 40-24700-101 1
R256 270k Ohm 2% 0,125W 1206 Philips 2322 711 41274 40-52700-102 1
R257 270k Ohm 2% 0,125W 1206 Philips 2322 711 41274 40-52700-102 1
R258 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R259 4,7 Ohm 5% 0,125W 1206 Philips 2322 711 61478 40-04700-101 1
R260 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R261 Res, Voltage Dependent Philips 2322-592-52506 41-22506-592 1
R263 2,7k Ohm 5% 0,125W 1206 Philips 2322 711 61272 40-32700-101 1
R264 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
T200 Input Txfr Protran 44-80270 44-80270 1
T201 Pre-Driver I/P Txfr Protran 44-80271 44-80271 1
T202 Pre-Driver O/P Txfr Protran 44-80272 44-80272 1
T203 Driver O/P Txfr Protran 44-80273 44-80273 1
T204 Output Txfr Codan 44-80274 44-80274 1
V200 Transistor, NPN Si SOT89 Philips BFQ17 BFQ17 1
Page 4 of 5
