Codan NGT 2010 RF User Manual

10 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05869-001 - PA Assy c/w Heatsink
BOM Revision
Date Valid On
C216 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C217 330p 5% 50V NPO 0805
NiSn
Philips 0805CG331J9B200 46-23300-081 1
C218 22p 5% 50V NPO 0805
NiSn
Philips 0805CG220J9B200 46-12200-081 1
C219 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C220 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C221 470p 5% 500V NPO 1210
NiSn
Philips 1210CG471GBB- 46-24700-082 1
C222 470p 5% 500V NPO 1210
NiSn
Philips 1210CG471GBB- 46-24700-082 1
C223 470p 5% 500V NPO 1210
NiSn
Philips 1210CG471GBB- 46-24700-082 1
C225 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C226 47p 5% 50V NPO 0805
NiSn
Philips 0805CG470J9B200 46-14700-080 1
C227 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C228 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C229 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C230 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C231 470n 10% 63V PE Cap Philips 2222 370 18474 46-54700-521 1
C232 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C233 100p 5% 50V NPO 0805
NiSn
Philips 0805CG101J9B200 46-21000-081 1
C234 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C235 22p 5% 500V NPO 1206
NiSn
Philips 1206CG220GBB- 46-12200-082 1
C236 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C237 100u 25V Ax EL Cap Elna RB 48-21002-551 1
C238 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C239 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
D202 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
D203 Diode, Zener 15V 5% 0,2W
SOT23
Philips BZX84-C15 BZX84C15 1
D204 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D205 Diode, 400V 1A SMA On Semiconductor MRA4004T3 MRA4004T3 1
D206 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D207 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
