11 -- Production
27.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
08-05416-001 - Filter & Control PCB
BOM Revision
Date Valid On
R54 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R55 3,9k Ohm 5% 0,125W 1206 Philips 2322 711 61392 40-33900-101 1
R56 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R57 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R58 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R59 120k Ohm 5% 0,125W 1206 Philips 2322 711 61124 40-51200-101 1
R60 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R61 82 Ohm 5% 0,125W 1206 Philips 2322 711 61829 40-18200-101 1
R62 33k Ohm 5% 0,125W 1206 Philips 2322 711 61333 40-43300-101 1
R63 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R64 470k Ohm 5% 0,125W 1206 Philips 2322 711 61474 40-54700-101 1
R65 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R66 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R67 39k Ohm 2% 0,125W 1206 Philips 2322-711-41393 40-43900-102 1
R68 5,6k Ohm 2% 0,125W 1206 Philips 2322-711-41562 40-35600-102 1
R69 1 Ohm 2% 0,125W 1206 Philips 2322 712 83108 40-01000-102 1
R70 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R71 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R72 47k Ohm 5% 0,125W 1206 Philips 2322 711 61473 40-44700-101 1
T1 Txfr, RF or Fetronics 44-80021 44-80021 1
V1 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V2 Transistor, PNP Si TO252 Motorola MJD32C MJD32C 1
V3 Transistor, NPN Si SOT23 Philips BCX20 BCX20 1
V4 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V5 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V6 MOSFET, N Chan Enhance
SOT23
Philips BST82 BST82 1
V7 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V8 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V9 Transistor, NPN Si SOT23 Philips BC848 BC848 1
Page 10 of 11
