09 -- Production

28.09.2006

Ref Descri

tion Manufacturer Manufacturer's P/N Codan P/N Qt

08-05910-001 - Filter & Control PCB

BOM Revision

Date Valid On

D5 Diode, Si High speed 75V

SOD80C

Philips BAS32L/S BAS32L/S 1

D6 Diode, Si High speed 75V

SOD80C

Philips BAS32L/S BAS32L/S 1

D7 Diode, Si High speed 75V

SOD80C

Philips BAS32L/S BAS32L/S 1

D8 Diode, Si High speed 75V

SOD80C

Philips BAS32L/S BAS32L/S 1

D9 Diode,PIN 150V 1ohm@10mA

700nsTrr SC79

Infineon BAR67-02V BAR67-02V 1

D10 LED, Green PLCC SMD Non

Diffused

Siemens LGT670-L 65-61110-507 1

D11 Diode, Si High speed 75V

SOT23

Philips BAS16 BAS16 1

D12 Diode, Si High speed 75V

SOT23

Philips BAS16 BAS16 1

D14 Diode, Schottky 70V 70mA

SOT23

Siemens BAS70 BAS70 1

D15 Diode, Si High speed 75V

SOT23

Philips BAS16 BAS16 1

IC1 Reg, Voltage +10V IC National Semiconduct LM2940T-10 XB-02940-402 1

IC2 Micro prgmd, RFU Filter I/O Arrow 90-20608-001 90-20608-001 1

IC3 Array, Transistor

SOIC14

Motorola MC1413D XT-01413-700 1

IC4 Reg, Voltage +5V 0,1A

SOIC8

National Semiconduct LM78L05ACM XB-07805-700 1

IC5 Amp, Oper Dual CMOS

SOIC8

National Semiconduct LMC662CM XA-00662-700 1

IC6 Amp, Operational Dual

SOIC8

National Semiconduct LM358M XA-00358-700 1

IC7 Comparator, Dual O/C Output

SOIC8

National Semiconduct LM393M XD-00393-700 1

J1 Socket, Coax Mini Low Prof

Fixed

Taiko Denki TMP-J02X-A1 60-19390-002 1

J2 Socket, MCX Straight

PCB

Chin Nan 27-05-TGN 60-19300 1

J3 Terminal Block 2 way PCB Phoenix Mecano AK300/2-5,0-GREY 61-10200-202 1

K1 Relay, 2C 12V 2A SMD 1028

Ohm
