02 -- Production
28.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
08-06260-001 - Appn Proc PCB, Handset & Data I/F
BOM Revision
Date Valid On
D3 Diode, Schottky SOT23 Philips BAT54 BAT54 1
H1 Not Fitted Codan **-00000-001 99-00000-001 1
H2 Not Fitted Codan **-00000-001 99-00000-001 1
H3 Not Fitted Codan **-00000-001 99-00000-001 1
H4 Not Fitted Codan **-00000-001 99-00000-001 1
IC1 CPLD prgmd, 2012 RFU DSP Braemac 90-20635-001 90-20635-001 1
IC2 UART, Quad 64b FIFO 3-5V
w/IrDA TQFP64
Exar ST16C654IQ64 YK-16654-910 1
IC3 Reg, Voltage +5V 0,1A
SOIC8
National Semiconduct LM78L05ACM XB-07805-700 1
IC4 Reg, Voltage +1,8V 150mA
LDO SOT23-5
Texas Instruments TPS76318DBVT XB-76318-700 1
IC5 Reg, Voltage +3,3V 0,5A
Switch SOIC8
National Semiconduct LM2674M-3.3TR XB-02674-701 1
IC6 Micro prgmd, 2011 Master I/O Codan 90-20624-001 90-20624-001 1
IC7 Codec, 16 Bit 22kSPS 3-5V
TQFP48
Texas Instruments TLV320AIC10C YN-32010-900 1
IC8 Amp, Oper Dual CMOS
SOIC8
National Semiconduct LMC662CM XA-00662-700 1
IC9 Serial Number, 48 bit
SOT223
Dallas DS2401Z YM-02401-700 1
IC10 Supervisory, Dual 2,93 & 1,68V
SOIC8
Texas Instruments TPS3305-18DR XD-03305-700 1
IC11 DSP, 32 Bit Fltng Point
60MIPS LQFP144
Texas Instruments TMS320VC33PGE120 YP-32033-900 1
IC12 FLASH prgmd, NGT SRx D0-
D15
Braemac 90-20636-101 90-20636-101 1
IC13 FLASH prgmd, NGT SRx D16-
D32
Braemac 90-20636-201 90-20636-201 1
IC14 RAM, CMOS 512kx16Bit 55ns
3V TSOP2-44
Samsung K6X8016T3B-UF55T YM-16512-710 1
IC15 RAM, CMOS 512kx16Bit 55ns
3V TSOP2-44
Samsung K6X8016T3B-UF55T YM-16512-710 1
IC16 Flash 1Mx8bit/512k x16bit 3V
70ns TSOP48
AMD AM29LV800BB-70EI YM-29800-710 1
IC17 Supervisory, Pwr&reset 4,63V
SOT23
Maxim MAX810LEUR-T XD-00810-700 1
IC18 Comparator, Rail-Rail I/O LP
SOT23-5
National Semiconduct LMC7221AIM5 XD-07221-700 1
IC19 Gate, OR 2 Input Quad
TSSOP14
STMicroelectronics 74LCX32TTR YX-74032-700 1
IC20 Buffer, Dual Bus T/State
VSSOP8
Texas Instruments SN74LVC2G125DCUT YX-74125-700 1
J1 Socket, 16way 1row ZIF 1mm
Pitch SMD
Global Shine GS008-16-G-1 60-00163-004 1
L1 Ind, 680uH Switched Supply Coilcraft DS5022P-684 43-82680-000 1
L2 Ind, 10uH 10% 4532 Taiyo Yuden LEM 4532T100K 43-81100-000 1
L3 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L4 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
P1 Not Fitted Codan **-00000-001 99-00000-001 1
P2 Header (P) 10way 2row Boxed
SMD 2,54mm
Neltron 2316SM-10G 60-00100-004 1
P3 Not Fitted Codan **-00000-001 99-00000-001 1
