01 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05976-001 - 500/1000W HF Filter PCB
BOM Revision
Date Valid On
C602 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C603 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C604 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C701 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C702 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C703 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C704 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
K101 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
K102 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
K201 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
K202 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
K301 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
K302 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
K401 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
K402 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
K501 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
K502 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
K601 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
K602 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
K701 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
K702 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
L101 Inductor, 3,6uH Lencom 44-70513 44-70513 1
L102 Inductor, 1,92uH Lencom 44-70514 44-70514 1
L103 Inductor, 2,2uH Lencom 44-70515 44-70515 1
L201 Inductor, 2,37uH Lencom 44-70516 44-70516 1
L202 Inductor, 1,3uH Lencom 44-70517 44-70517 1
L203 Inductor, 1,3uH Lencom 44-70517 44-70517 1
L301 Inductor, 1,5uH Lencom 44-70518 44-70518 1
L302 Inductor, 835nH Lencom 44-70519 44-70519 1
L303 Inductor, 835nH Lencom 44-70519 44-70519 1
L401 Inductor, 1,02uH Lencom 44-70520 44-70520 1
L402 Inductor, 555nH Lencom 44-70521 44-70521 1
L403 Inductor, 555nH Lencom 44-70521 44-70521 1
L501 Inductor, 555nH Lencom 44-70521 44-70521 1
L502 Inductor, 364nH Lencom 44-70525 44-70525 1
L503 Inductor, 405nH Lencom 44-70526 44-70526 1
L601 Inductor, 428nH Lencom 44-70522 44-70522 1
Page 3 of 4
