05 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05979-001 - Control PCB 500W HF Amp
BOM Revision
Date Valid On
IC104 Driver, 8 Bit Serial I/P,latched
SOIC20
Allegro A5841SLW YK-05841-700 1
IC105 Amp, Op Rail-Rail I/O Dual
SOIC8
National Semiconduct LMC6482IM XA-06482-700 1
IC106 Amp, Op Rail-Rail I/O Dual
SOIC8
National Semiconduct LMC6482IM XA-06482-700 1
IC107 Buffer, Hex Inverting Schmitt
SOIC14
Motorola MC74HC14D YH-74014-700 1
IC108 Gate, AND 2 Input Quad
SOIC14
Motorola MC74HC08AD YH-74008-700 1
IC109 Amp, Op Rail-Rail I/O Dual
SOIC8
National Semiconduct LMC6482IM XA-06482-700 1
IC110 Amp, Op Rail-Rail I/O Dual
SOIC8
National Semiconduct LMC6482IM XA-06482-700 1
IC201 Amp, Op Rail-Rail I/O Dual
SOIC8
National Semiconduct LMC6482IM XA-06482-700 1
IC202 Amp, Op Rail-Rail I/O Dual
SOIC8
National Semiconduct LMC6482IM XA-06482-700 1
IC203 Amp, Op Rail-Rail I/O Dual
SOIC8
National Semiconduct LMC6482IM XA-06482-700 1
IC204 Amp, Op Rail-Rail I/O Dual
SOIC8
National Semiconduct LMC6482IM XA-06482-700 1
IC205 Amp, Op Rail-Rail I/O Dual
SOIC8
National Semiconduct LMC6482IM XA-06482-700 1
IC206 Amp, Op Rail-Rail I/O Dual
SOIC8
National Semiconduct LMC6482IM XA-06482-700 1
IC207 Amp, Op Rail-Rail I/O Dual
SOIC8
National Semiconduct LMC6482IM XA-06482-700 1
IC208 Driver, Lin Dot/Bar Display
PLCC20
National Semiconduct LM3914V XA-03914-900 1
P101 Header (P) 10way 2row Boxed
Fix
I-Technos HDM410S02 60-00100-003 1
P102 Header (P) 6way 2mm Latch
Fixed
AMP 173981-6 60-00060-350 1
P103 Header (P) 10way 2row Boxed
Fix
I-Technos HDM410S02 60-00100-003 1
P104 Not Fitted Codan **-00000-001 99-00000-001 1
P105 Header (P) 10way 2row Boxed
Fix
I-Technos HDM410S02 60-00100-003 1
P106 Header (P) 10way 2row Boxed
Fix
I-Technos HDM410S02 60-00100-003 1
P107 Header (P) 10way 2row Boxed
Fix
I-Technos HDM410S02 60-00100-003 1
P201 Header (P) 10way 2row Boxed
Fix
I-Technos HDM410S02 60-00100-003 1
P202 Header (P) 10way 2row Boxed
Fix
I-Technos HDM410S02 60-00100-003 1
P203 Not Fitted Codan **-00000-001 99-00000-001 1
P204 Header (P) 2way 1row Latch JAE IL-2P-S3EN2 60-00020-260 1
R101 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R102 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R103 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R104 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
Page 5 of 10
