Codan NGT 2010 RF User Manual

05 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05979-001 - Control PCB 500W HF Amp
BOM Revision
Date Valid On
R259 3,9k Ohm 5% 0,1W 0805 Philips 2322 730 61392 40-33900-111 1
R260 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R261 150k Ohm 5% 0,1W 0805 Philips 2322 730 61154 40-51500-111 1
S201 Switch, Toggle SPDT on-on C&K 7101-P3-Y-Z-Q-E 62-01220-000 1
V101 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V102 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V103 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V104 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V105 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V106 Not Fitted Codan **-00000-001 99-00000-001 1
V107 MOSFET, Power N channel
TO252
Motorola MTD3055EL MTD3055EL 1
V108 MOSFET, Power N channel
TO252
Motorola MTD3055EL MTD3055EL 1
V109 MOSFET, Power N channel
TO252
Motorola MTD3055EL MTD3055EL 1
V110 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V201 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V202 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V203 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V204 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V205 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V206 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V207 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V208 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V209 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V210 Transistor, NPN Si SOT23 Philips BC848 BC848 1
Page 10 of 10
