Codan NGT 2010 RF User Manual

07 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05854-001 - NRI Micro-Controller PCB
BOM Revision
Date Valid On
IC204 Tcvr, CAN bus
SOIC8
Philips PCA82C250T YI-82250-700 1
IC205 Serial Number, 48 bit
SOT223
Dallas DS2401Z YM-02401-700 1
IC206 SRAM, CMOS 256k x 16 Bit
20ns SOJ44
Alliance AS7C4098-20JC YM-74098-700 1
IC207 FLASH, Serial 512k x 8 Bit 3V
SOIC8
Atmel AT45DB041B-SC YM-45041-700 1
IC208 Cntlr, CAN bus 2,0B
SOIC28
Philips SJA1000T/N1 YL-81000-700 1
IC209 FLASH prgmd, NRI Codan 90-20604-101 90-20604-101 1
IC210 Gate, AND 2 Input Quad
SOIC14
Motorola MC74AC08D YS-74008-700 1
IC211 Buffer, Single Non-Inv T/State
SOT323-5
STMicroelectronics 74V1T125CTR YY-74125-700 1
L101 Ind, 10uH 10% 4532 Taiyo Yuden LEM 4532T100K 43-81100-000 1
L102 Ind, 100uH 1,2A SMPS
SMD
Epcos B82476-A1104-M 43-82100-003 1
P101 Header (P) 10way 2mm Latch
Fixed
AMP 1-173981-0 60-00100-351 1
P201 Header (P) 26way 2row Boxed
Fix
Thomas & Betts 609-2627 60-00260-000 1
P202 Header (P) 10way 2mm Latch
Fixed
AMP 1-173981-0 60-00100-351 1
P204 Header (P) 50way 2row Fixed
1,27mmP SMD
Samtec TFML-125-02-S-D 60-00500-000 1
R101 2,2k Ohm 5% 0,06W 0603 Philips 2322 702 60222 40-32200-121 1
R102 4,7k Ohm 5% 0,06W 0603 Philips 2322 702 60472 40-34700-121 1
R103 4,7k Ohm 5% 0,06W 0603 Philips 2322 702 60472 40-34700-121 1
R104 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R105 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R106 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R107 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R108 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R109 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R110 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R111 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
R112 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
R113 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R114 47 Ohm 5% 0,06W 0603 Philips 2322 702 60479 40-14700-121 1
R115 47 Ohm 5% 0,06W 0603 Philips 2322 702 60479 40-14700-121 1
R116 1M Ohm 5% 0,06W 0603 Philips 2322 702 60105 40-61000-121 1
