Codan NGT 2010 RF User Manual

01 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05870-001 - NRI Vocoder PCB
BOM Revision
Date Valid On
IC4 Reg, Voltage -5V 0,1A
SOIC8
National Semiconduct LM79L05ACM XB-07905-700 1
IC5 DSP, Speech Compression
Duplex PQFP128
DSP Group CT8020D11AQC YP-08020-900 1
IC6 RAM, CMOS 64k x 8Bit 12nS
SOJ28
Alliance AS7C256-10JC YM-07256-700 1
J1 Socket, 50way 2row Fixed
1,27mmPitch SMD
Samtec SFML-125-T2-S-D 60-00503-000 1
L1 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
R1 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
R2 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
R3 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
R4 10 Ohm 5% 0,06W 0603 Philips 2322 702 60109 40-11000-121 1
R5 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
R6 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R7 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R8 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
R9 150k Ohm 5% 0,06W 0603 Philips 2322 702 60154 40-51500-121 1
R10 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R11 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R12 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R13 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R14 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R15 100 Ohm 5% 0,06W 0603 Philips 2322 702 60101 40-21000-121 1
R16 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R17 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R18 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R19 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R20 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R21 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R22 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R23 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R24 100 Ohm 5% 0,06W 0603 Philips 2322 702 60101 40-21000-121 1
Page 2 of 3
