Appendix B: Ordering Information
HEU and OIU Assemblies and Modules
Part Number
Description
HEU:
Headend Unit assembly (without RIMs); support for 1-12 RIMs:
HEU-2-00-1-A-H Hosts two RIX modules; one PSM-AC module and one HCM module
HEU-2-00-1-D-H Hosts two RIX modules; one PSM-DC module and one HCM module
HEU-2-00-1-A-A Hosts two RIX modules; one PSM-AC module and one ACM module
HEU-2-00-1-D-A Hosts two RIX modules; one PSM-DC module and one ACM module
HEU-1-00-1-A-H Hosts one RIX module; one ETM module; one PSM-AC and one HCM module
HEU-1-00-1-D-H Hosts one RIX module; one ETM module; one PSM-DC and one HCM module
HEU-1-00-1-A-A Hosts one RIX module; one ETM module; one PSM-AC and one ACM module
HEU-1-00-1-D-A Hosts one RIX module; one ETM module; one PSM-DC and one ACM module
HEU Modules:
HCM Head End Control Module; Includes two RJ-45 cables (2 m)
RIX Radio Interface Expander – HEU expansion module; two must be ordered
RIM: Radio Interface Module for HEU chassis
RIM-L70 LTE 700 MHz service
RIM-C85 CELL 850 service MHz service
RIM-P19 PCS 1900 MHz service
RIM-A17 AWS 1700 MHz service
RIM-L70-M LTE 700 MHz MIMO service
RIM-A17-M AWS 1700 MHz MIMO service
OIU
Optical Interface Unit assembly (without OIMs); support for 1-12 Optical Interface
Modules
OIU-2-00-1-A-A Hosts two OIX modules, one PSM-AC module and one ACM module
OIU-2-00-1-D-A Hosts two OIX modules, one PSM-DC module and one ACM module
OIU-1-00-1-A-A Hosts one OIX module; one ETM module; one PSM-AC and one ACM module
OIU-1-00-1-D-A Hosts one OIX module; one ETM module; one PSM-DC and one ACM module
OIU Modules:
OIM Optical Interface Module for OIU Chassis; three Optical links
Additional HEU and OIU Modules
ACM Auxiliary Control Module; Includes two RJ-45 cables (2 m)
PSM-AC AC Power Supply – installed in HEU and OIU chassis; includes US plug power cords
PSM-DC
DC Power Supply - installed in HEU and OIU chassis; includes 48 V DC six pin
terminal block connector
ETM Expander Termination Module; 50 Ohm; used for terminating unoccupied RIX/OIX slot
