Appendix B: Specifications
Supported Services
Technology
Frequency Range (MHz)
Service/Band Uplink (UL) Downlink (DL)
LTE 700 MHz 698-716
777-787
728-746
746-756
CDMA/WCDMA**/ TDMA/GSM/LTE* CELL 800 824-849 869-894
CDMA/WCDMA**/TDMA/GSM/LTE* PCS 1900 1850-1915 1930-1995
WCDMA**/LTE* AWS 2100 1710-1755 2110-2155
*WCDMA service is based on 3GPP standards, LTE service may deployed in the future due to Frequencies re-farming planned by the Carriers as well
**WCDMA service is based on 3GPP2 CDMA2000 standards.
RF Parameters per Service
Service/Band
LTE
700 MHz
CELL
800 MHz
PCS
1900 MHz
AWS
2100 MHz
RF Parameter DL UL DL UL DL UL DL UL
Frequency Range
(MHz)
728-746
746-756
698-716
777-787
869-894 824-849 1930-1995 1850-1915 2110-2155 1710-1755
Max Output Power Per
Antenna Port (dBm)
14 14 17 18
Max Input Power (dBm)
0 to 37 0 to 37 0 to 37 0 to 37
Mean Gain (dB)
-19 to 10 -19 to 10 -19 to 10 -19 to 10
Input IP3 (dBm) AGC
OFF Min
-5 -5 -5 -5
Input IP3 (dBm) AGC
ON Min
5 5 5 5
SFDR** (dB)
59 63 63 59
Max Intermod
Distortion (dBm)
-13 -13 -13 -13
UL NF*(dB)
12 12 12 12
Gain Flatness/Ripple
(dB)
±2.0 ±2.0 ±2.0 ±2.0
*Typical for single remote antenna
** SFDR calculated with BW of 1.23MHz for the CELL and PCS and with 5MHz for the LTE and AWS
