1.3.2.2 Safety and Regulatory Approvals
The safety and regulatory specifications listed below are relevant to all ONE™ devices.
Regulation/Standard
Category
Approval
Laser Safety
FDA/CE 21 CFR 1040.10 and 1040.11 except for deviations pursuant to laser notice
no. 50 and IEC 60825-1
EMC
CE EN 301 489, EN55022, EN 61000
FCC 47 CFR Part 15, 22, 24, 27
Safety
UL 60950
IEC 60825-1:2007
IEC 60825-2:2010
CAN/CSA-C22.2 No.60950-1-03
Fire Safety UL 2043 (applicable for Access Unit only)
Table 1-2. Safety and Regulatory Approvals
1.3.3 Power Specifications
1.3.3.1 Power Input and Consumption
RF Head End Units Power Input Power Consumption for Full Chassis
HEU AC power source: 100 to 220 V AC
Chassis with 12 RIMs and two RIX: 200 W
DC power source: 48 V DC
OIU AC power source: 100 to 220 V AC
Chassis with 12 OIMs and two OIX: 300 W
DC power source: 48 V DC
Table 1-3. RF Headend Units Power Consumption
RAU + Add-On Modules
Max. Power Consumption
Power Input Range
RAU (alone)
37 V; 35 W
35 – 57 V DC
RAU + RxU
37 V; 60 W
RAU + GEM
37 V; 39 W
RAU + RxU + GEM 37 V; 64 W
Table 1-4. RAU Power and Current Consumption for Main Power Input
Device Input Range Power Consumption
For two PoE ports of 802.3af 43- 57 V DC 43 V; 30 W
For two PoE ports of 802.3at 52- 57 V DC 52 V; 62 W
Table 1-5. RAU Power and Current Consumption for Main Secondary Input
Digital Remote End Units Power Input Range Power Consumption
CEU 110 to 240 V AC (Fully occupied) 50 W
GEM installed in RAU
See Table 1-4 See Table 1-4
GEU-S 42-57 V DC 4.5 W
