5.2.2.6 RAU Mid-Mount Installation Option
The RAU mid-mount bracket accessory kit (AK-RAU-BRCK-MM; ordered separately) provide an aesthetic solution for a
installing the RAU in mid-mount of an acoustic ceiling. The kit includes a tile like panel onto which the RAU is mounted and
which replaces a standard acoustic ceiling tile.
Figure 5-57. RAU Mid-Mount Complete Assembly – Top (Right) and Bottom (Left) View
RAU Mid-Mount Bracket Accessory kit Items
Item No. Description Quantity
1
Plate
1
2
Spacer 1
3
Assembled flat bar 1
4
Nylon four arm knob with threaded stud 1
