1.3.4 Dimensions and Weight of Units
Table 1-14, Table 1-15 and Table 1-16 describe the physical specifications of the ONE™ headend and remote end units.
Unit Dimensions (H x W x D) Weight:
HEU 7 x 17.3 x 18.95 in (177.8 x 440 x 481.7 mm) Chassis: 37 lbs (16.8 kg)
Per RIM: 1.9 lbs (0.9 kg)
Per RIX: 1.54 lbs (0.7 kg)
HCM: 2.2 lbs (1.0 kg)
PSM: 1.98 lbs (0.9 kg)
OIU 7 x 17.3 x 18.95 in [177.8 x 440 x 481.7 mm] Chassis: : 37 lbs (16.8 kg)
Per OIM: 1.5 lb (0.7 kg)
Per OIX: 1.54 lb (0.7 kg)
ACM: 2.2 lb (1.0 kg)
PSM: 1.98 lb (0.9 kg)
Table 1-14. RF Path Headend Units
Unit Dimensions (H x W x D) Weight:
ICU 1.74 x 17 x 19.2 in (44.4 x 431.8 x 11.96 mm) 5.5 lb (2.5 kg) – without PSM
RAU (including
mounting bracket)
13.1 x 13.1 x 4 in (332.7 x 332.7 x 101.6 mm)
RAU only = 7.93 lb (3.6 kg);
RAU + RxU + GEM = 12.2 lb (5.5 kg)
Table 1-15. RF Path Remote Units
Unit Dimensions (H x W x D) Weight: lbs [kg]
CEU 1.71 x 17 x 8.5 in (43.65 x 431.8 x 216 mm) -
GEM 1.28 x 3.79 x 5.95 in (32.7 x 96.3 x 151.3 mm) 1.1 lb (0.5 kg)
GEU-S 5.01 x 10.51 x 3.26 in (including mounting bracket)
(127.5 x 267 x 83 mm)
2.64 lb (1.2 kg)
Table 1-16. Digital Path Units
