CORNING ONE - Remote End Distance and Power Draw Matrix

Introduction P/N 709C011801 Page 19
DRAFT
Ceilings
P/N
Description
Min-Max
Voltage
(VDC)
Max Power
Draw (Watts)
Heat
(BTU/hr)
Dimensions (in)
RAU Remote Access Unit
37 - 57 35 119 13.1 x 13.1 x 4
RxU Remote Expansion Unit
37 - 57 25 85 1.1 x 12.8 x 9.8
RAU + RxU
Remote Access Unit + Remote
Expansion Unit
37 - 57 60 204 13.1 x 13.1 x 4
GEM Gigabit Ethernet Module
37 - 57 4 14 1.3 x 3.8 x 5.9
GEU-S Gigabit Ethernet Unit - Standalone
37 - 57 4 14 5 x 10.5 x 3.3
GEM Supporting
PoE
For two PoE ports of 802.3af: 43V; 30W
For two PoE ports of 802.3at: 52V; 62W
Table 1-9. Power, Heat and Rack Specifications for Ceiling Equipment (Remote End)
1.3.3.4 Remote End Distance and Power Draw Matrix
Table 1-10, Table 1-11, Table 1-12 and Table 1-13 provide the distance and power draw specifications for the remote end units.
RAU SISO
Composite 16 AWG
Tether Distance (ft.)
Draw (Watts)
10 - 50 36
60 - 270 37
280 - 480 38
490 - 690 39
700 - 850 40
860 - 900 41
*Min/Max VDC = 37/57 @ 1.49 Amps, 85% efficiency
Table 1-10. Remote End Distance and Power Draw for (Standalone) RAU SISO
RAU + RxU (MIMO)
Composite 16 AWG
Tether Distance (ft.)
Draw (Watts)
Composite 16 AWG
Tether Distance (ft.)
Draw (Watts)
10 – 100 62 570 – 610 70
110 – 170 63 620 – 660 71
180 – 240 64 670 – 710 72
250 – 320 65 730 – 750 73
330 – 380 66 760 – 790 74
390 - 440 67 800 – 830 75
450 - 510 68 840 – 860 76
520 - 560 69 870 - 900 77
*Min/Max VDC = 37/57@ 1.49 Amps, 85% efficiency
