Introduction P/N 709C011801 Page 20
DRAFT
Table 1-11. Remote End Distance and Power Draw for RAU + RxU (MIMO)
GEM Supporting PoE 802.3af
Composite 16 AWG
Tether Distance (ft.)
Draw (Watts)
10 - 40 31
50 - 340 32
350 - 660 33
670 - 890 34
900 35
*Min/Max VDC = 43/57 @ 1.49 Amps, 85% efficiency
Table 1-12. Remote End Distance and Power Draw for GEM w/PoE.3af
GEM Supporting PoE 802.3at
Composite 16 AWG
Tether Distance (ft.)
Draw (Watts)
Composite 16 AWG
Tether Distance (ft.)
Draw (Watts)
10 - 80 64 590 - 620 73
90 - 170 65 630 - 670 74
180 - 230 66 680 - 710 75
240 - 300 67 720 – 750 76
310 - 370 68 760 – 790 77
380 - 420 69 800 - 820 78
430 - 470 70 830 - 850 79
480 - 530 71 860 - 890 80
540 - 580 72 900 81
*Min/Max VDC = 52/57 @ 1.49 Amps, 85% efficiency
Table 1-13. Remote End Distance and Power Draw for GEM w/PoE.3at
