Appendix A: RAU Upgrades P/N 709C011801 Page 136
C. Connect the Secondary 48V feed to the RAU and Wait 1-2 seconds. Verify status of GEM LEDs according to Table 6-4:
LED Expected Description of expected indication
RUN Flashing
(10/Sec)
SW and CPU running normally
Ethernet
LINK
Off
Ethernet
ACTIVITY
Off
SFP LINK Off
POE Off
48V feed to PoE circuitry exist and PoE OFF
Table 6-4.GEM Secondary Power LED Status
D. After SECONDARY POWER is connected, wait 1-2 seconds and verify GEM LEDs:
LED Indication Expected
(GEM) RUN OK Flashing Green (10/Sec)
Ethernet LINK Link Off
Ethernet ACT Activity Off
(SFP) LINK Link\Activity Off
PoE POE status Off
To Next Page
