Installation – RF Path Elements P/N 709C011801 Page 78
MTP-LC APC Harness Cable (P/N 37HP900162-06F) - connector for
splitting fibers (6) leading from OIM to (FMU) Edge module
1
PSM Kit (AC or DC modules - 1 or 2 kits according to order)
Quantity
PSM-AC: 100-240 VAC Power Supply Module including standard
IEC 60320-1 C13 cable
1
PSM-DC: 48 V DC Power Supply Module; 9 A Max.; Includes six pin
terminal block connector
1
OIU Expander Module Kit (1 or 2 according to order) Quantity Item
OIX (Optical Interface Expander Module) – connects to the HEU RIX
Expander module; provides RF interface to HEU
1
ETM Kit (according to order) Quantity Item
ETM (Expander Termination Module) - used for terminating unused
Expander slot
1
ACM Kit Quantity Item
ACM (Auxiliary Control Module) – enables remote (via HCM)/local
management of all hosted units
1
