xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
226
Max Response Time
Enter a value between 1 and 25 to specify the maximum amount of time allowed
before sending an MLD response report. The default time is 10 seconds.
Robustness Variable
(2-7)
A tuning variable to allow for sub-networks that are expected to lose a large number
of packets. A value between 2 and 7 can be entered, with larger values being
specified for sub-networks that are expected to lose larger numbers of packets. The
Last Member Query
Interval (1-25)
Enter a value between 1 and 25 to specify the maximum amount of time between
group-specific query messages, including those sent in response to leave group
messages. The default is 1 second.
Click the <<Back button to return to the previous window.
Click the Apply button to accept the changes made.
MLD Group Table
The window is used to display the MLD static groups on the Switch.
To view the following window, click L3 Features > IP Multicast Routing Protocol > MLD > MLD Group Table, as
shown below:
Figure 5-100 MLD Group Table window
The fields that can be configured are described below:
Parameter Description
Enter the IP interface name used for this configuration.
Enter the IPv6 multicast group address.
Click the Find button to find the interface entered.
Click the View All button to view all the interfaces configured on this switch.
Click the View Detail link to view more information regarding the specific entry.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Click the View Detail link to see the following window.
Figure 5-101 MLD Group Detail Information window
