xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide
405
Figure 9-8 DHCP Relay Option 61 Settings window
The fields that can be configured are described below:
Parameter Description
DHCP Relay Option
61 Default
Here the user can select the DHCP Relay Option 61 default action.
Drop – Specify to drop the packet.
Relay – Specify to relay the packet to an IP address. Enter the IP Address of the
default relay server. When there is no matching server found for the packet based on
Option 61, the relay servers will be determined by this default relay server setting.
Client ID MAC Address – The client’s client-ID which is the hardware address of client.
String – The client’s client-ID, which is specified by administrator.
Relay Rule Drop – Specify to drop the packet.
Relay – Specify to relay the packet to an IP address.
Client ID MAC Address – The client’s client-ID which is the hardware address of client.
String – The client’s client-ID, which is specified by administrator.
Click the Apply button to accept the changes made.
Click the Add button to add a new entry based on the information entered.
Click the Delete button to remove the specific entry based on the information entered.
Click the Delete All button to remove all the entries listed.
DHCP Relay Option 82 Port Settings
This window is used to configure the DHCP relay agent option 82 information of each port.
To view this window, click Network Application > DHCP > DHCP Relay > DHCP Relay Option 82 Port Settings
as shown below:
