200508 2-3
Inspection and adjustment
MECHANICAL GEARBOX CONTROL
ΛΦ45/55 series
3
2
11. Tighten the lock nuts (2) on the torque rod to
the specified torque without moving the
torque rod. See "Technical data".
12. Remove the special tool from the ball joint.
13. Clean part (A) of the control rod and remove
any grease.
14. Apply the specified lubricant lightly to section
(B) of the control rod. See "Technical data".
15. Remove the special tool and fit the gaiter.
See "Removal and installation".
16. Fit the switch button. See "Removal and
installation".
V3 00 746
B
A
DAF LF Gearboxes and Clutch Service Manual
