How to Program
0-14 Readout: Edit Set-u ps / Channel
Range:
0 - FFF.FFF.FFF
*
AAA.AAA.AAA
Function:
View the setting of par. 0 -11 Edit Set-up for each of
the four different communication channels. W hen
the number is dis played in hex, as it is in the LCP,
each number represent s one channel.
Numbers 1-4 represent a set-up number; ‘F’
means factory setting ; and ‘A’ means active
set-up. The channels are, from right to left:
LCP, FC-bus, USB, HPFB1.5.
Example: The number AAAAAA21h means
that the FC bus selected Set-up 2 in par.
0-11,theLCPselectedSet-up1andallothers
usedtheactiveset-up.
" 0-2* LCP D isplay
Define the display in the Graphical Logic
Control Panel.
0-20 Display Line 1 .1 Small
None [0]
Profibus Warning Word [953]
Readout Transmit E rror Counter [1005]
Readout Receive Error Counter [1006]
Readout Bus Off Counter [1007]
Warning Parameter [1013]
Running Hours [1501]
kWh C ounter [1502]
Control Word [1600]
Reference [Unit] [1601]
Reference % [1602]
Status Word [1603]
Main Actual Value [%] [1605]
Custom Readout [1609]
Power [kW] [1610]
Power [hp] [1611]
Motor Voltage [1612]
Frequency [1613]
Motor Current [1614]
Frequency [%] [1615]
To rq ue [1 616]
* Sp eed [RPM ] [1617]
Motor Therm al [1618]
KTY Sensor Temperature [1619]
Motor Angle [1620]
Phase Angle [1621]
DC Link Voltage [1630]
BrakeEnergy/s [1632]
BrakeEnergy/2 m in [1 633 ]
Heatsink Tem p. [1634]
Inverter Therma l [1635]
Inv. Nom. Current [163 6]
Inv. Max. Current [1637]
SL Control State [1638]
Control Card Tem p. [1639]
External Reference [1650]
Pulse Reference [1651]
Feedback [Unit] [1652]
DigiPot Reference [1653]
Digital Input [1660]
Terminal 53 Switch Setting [1661]
Analog Input 53 [1662]
Terminal 54 Switch Setting [1663]
Analog Input 54 [1664]
Analog Output 42 [mA] [1665]
Digital Output [bin] [1666]
Freq. Input #29 [H z] [1667]
Freq. Input #33 [H z] [1668]
Pulse Output #27 [Hz] [1669]
Pulse Output #29 [Hz] [1670]
Relay Output [bin] [1671]
Counter A [167 2]
Counter B [1673]
Ser. Com . Bus CTW 1 [1680]
Ser. com. bus REF 1 [1682]
Comm. Option STW [1684]
FC Port CTW 1 [1685]
FC Port REF 1 [1686]
Alarm Word [1690]
Alarm Word 2 [1691]
Warning Word [1692]
Warning Word 2 [1693]
Ext. Status Word [1694]
Ext. Status Word 2 [1695]
PCD 1 Write to M CO [3401]
PCD 2 Write to M CO [3402]
PCD 3 Write to M CO [3403]
PCD 4 Write to M CO [3404]
PCD 5 Write to M CO [3405]
PCD 6 Write to M CO [3406]
PCD 7 Write to M CO [3407]
PCD 8 Write to M CO [3408]
PCD 9 Write to M CO [3409]
PCD 10 Write to M CO [3410]
PCD 1 Read from MCO [342 1]
PCD 2 Read from MCO [342 2]
PCD 3 Read from MCO [342 3]
PCD 4 Read from MCO [342 4]
PCD 5 Read from MCO [342 5]
PCD 6 Read from MCO [342 6]
PCD 7 Read from MCO [342 7]
PCD 8 Read from MCO [342 8]
PCD 9 Read from MCO [342 9]
PCD 10 Read from MCO [3430]
Digital Inputs [ 3440]
Digital Outputs [3441]
Actual Position [3450]
Commanded Position [3451]
Actual Master Position [3452]
*
default setting ()display text []value for use in communication via serial communication port
154
MG.33.B
