FC 300 Design Guide
How to Program
Slave Index Position [3453]
Master Index Position [3454]
Curve Position [3455]
Track Error [3456]
Synchronizing Error [3457]
Actual Velocity [3458]
Actual Master Velocity [3459]
Synchronizing S tatus [3460]
Axis Status [3461]
Program Status [3462]
Idle Time [9913]
Paramdb Requests in Queue [9914]
Analog input X 30/11 [1675]
Analog input X 30/12 [1676]
Analog output X30/8 mA [1677]
Function:
Select a variable for display in line 1, left position.
None [0] No display value s elected
Control Word [1600] Present control word
Reference [Unit] [160 1] Total reference (sum of
digital/analog/preset/b us/freeze ref./catch-up
and slow-down) in selected unit.
Reference % [1602] Total reference (sum of
digital/analog/preset/b us/freeze ref./catch-up
and slow-down) in perc ent.
Status Word [binary] [1603] Present status word
Main actual value [1605] [Hex] One or more
warnings in a Hex code
Power [kW] [ 1610] Actual p ow er consumed
by the motor in kW.
Power [hp] [1611] Actual power consumed
by the motor in HP.
Motor Voltage [V] [1612] Voltage sup-
plied to the motor.
Frequency [Hz] [1613] Motor frequency, i.e.,
the output frequency from the adjustable
frequency drive in Hz.
Motor Current [A] [1614] Phase current of the
motor measured as an effective value.
Frequency [ %] [1615] Motor frequency, i.e.,
the output frequency from the adjustable
frequency drive in percent.
Torque [%] [1616 ] Present motor load as a
percentage of the rated mo tor torque.
*Speed [RPM] [16 17] Spee d in RPM (revolutions per
minute), i.e., the m otor shaft speed in closed loop.
Motor thermal [1618] Thermal load on the motor,
calculated by the ETR function.
DC L ink Voltage [V] [1630] Intermediat e circuit
voltage in the adjustable frequency drive.
BrakeEnergy/s [1632] Present braking energy
transferred to a n external brake resistor.
Stated as an instantaneous value.
BrakeEnergy/2 min [1633] Braking energy
transferred to an external brake resistor.
The mean power is calculated continuously
for the latest 120 seconds.
Heatsink Temperature [°C] [1634] Pre sent heatsink
temperature of the adjustable frequency drive.
The cut-out limit is 203 ± 9°F [95 ±5°C]; cutting
back in occurs at 158 ± 9°F [70 ± 5°C].
Inverter thermal [1635] Percentage load
of the inverters.
Inv. Nom. Current [1636] Nominal current of
the adjustable freque n cy drive.
Inv. Max. Current [1637] Ma xim um current
of the adjustable frequency drive.
Condition control state [1638] State of the
event executed by the control.
Control Card Temperature [1639] Temperature
of the control card.
External Reference [1650] [%] Sum of the
external reference as a percentage, i.e., the
sum o f analog/pulse/bus.
Pulse Reference [1651] [Hz] Frequency in Hz
connected to the digital inputs (18, 19 or 32, 33).
Feedback [Unit] [1652] Reference value from
programmed digital input(s).
Digital Input [166 0] Sig nal states form the 6
digital terminals (18, 19, 27, 29, 32 and 33).
Input 18 corresponds to the bit at the far left.
Signal low = 0; Signal h ig h = 1 Terminal 53
Switch Setting [1661] Se tting of inp ut t erm inal
54. Current=0;Voltage=1.
Analog Input 53 [1662] Actual value at input 53
either as a reference or protection value.
Terminal 54 Switch Setting [1663] Setting of input
terminal 54. Current = 0; Voltage = 1.
Analog Input 54 [1664] Actual value at input 54
either as reference or protection value.
Analog Output 42 [mA] [1665] Actual value
at output 42 in mA. Use par. 6-50 to select
the value to be shown.
Digital output [bin] [1 66 6] Binary value
of all digital outputs.
Frequency i nput #29 [Hz] [1667] Actual value
of the
frequency applied at terminal 29 as a n impulse input.
Frequency i nput #33 [Hz] [1668] Actual value of the
frequency applied at terminal 33 as a n im
pulse input.
*
default setting ()display text []value for use in communication via serial communication port
155
MG.33.B
6.22 - V LT is a registered Danfoss trademark
