Danfoss FC 300 Design Guide

FC 300 Design Guide
How to Program
Pulse o utput #2 7 [Hz] [166 9] Actual value
of im pulses applied to terminal 27 in
digital output mode.
Pulse o utput #2 9 [Hz] [167 0] Actual value
of im pulses applied to terminal 29 in
digital output mode.
Ser. com. bus control word1 signal [1680] Control
word (CTW ) received f rom the bus maste r.
Ser. com. bus speed set-point A signal
[1682] Main reference value sent with control
word from the b us master.
Communication Option Status Word [binary]
[1684] Extended ser. communication bus
option status word.
FC port c ontrol word1 signal [1685] Control word
(CTW) rece ived from the bus master.
FC port speed set-point A signal [1686] Status
word (STW) sent to the bus master.
Alarm word [Hex] [1690] One or more
alarms in a Hex code.
Alarm word 2 [Hex] [1691] One or more
alarms in a Hex code.
Warning word [Hex] [1 692 ] One or more
warnings in a Hex code.
Warning word 2 [Hex] [1693] One or more
warnings in a Hex code.
Ext. status word [Hex] [1694] One or more
status conditions in a Hex code.
Ext. status word 2 [Hex] [169 5] One or more
status conditions in a Hex code.
0-21 Display Line 1 .2 Small
Option:
*
Motor Current [A] [1614]
Optionsarethesameasinpar. 0-20.
Function:
Select a variable for display in line 1, middle
position. The options are the same a s those listed
for par. 0-20 D isplay Line 1.1 Small.
0-22 Display Line 1 .3 Small
*
Power [kW] [1610]
Function:
Select a variable for display in line 1 , right position.
Theoptionsarethesameasthoselistedfor
par. 0-20 Display Line 1.1 Small.
0-23 Display Line 2 Large
*
Frequency [Hz] [1613]
Function:
Select a variable for display in line 2. The
options are the same as those liste d for p ar.
0-20 Display Line 1.1 Small.
0-24 Display Line 3 Large
Option:
*
Reference [%] [1602]
Options are the same as in par. 0-20.
Function:
Select a variable for display in line 3. The
options are the same as those liste d for p ar.
0-20 Display Line 1.1 Small.
0-25 My Personal Menu
Array [ 20]
Range:
0 - 9999
Function:
Define up to 20 parameters to include in the Q 1
Personal Menu, accessible via the [Quick Menu]
key on the LCP. Th e parameters will be displayed
in the Q1 Personal Menu in the order they are
programmed into this array parameter. Delete
parameters by setting the value to ‘0000’.
" 0-4* LCP Keypad
Enable and disable individual keys on
the LCP keypad .
0-40 [Hand on] Key on LCP
Option:
Disabled [0]
*
Enabled [1]
Password [2]
*
default setting ()display text []value for use in communication via serial communication port
156
MG.33.B
6.22 - V LT is a registered Danfoss trademark
