*No operation [0]
MCO controlled [51]
Output frequency [100]
Reference [101]
Feedback [102]
Motor current [103]
Torque relative to limit [104]
Torque relative to rated [105]
Power [106]
Speed [107]
Torque [108]
Function:
Parameters for configuring the scaling and
output functions of pulse outputs. The pulse
outputs are design ated to terminals 27 or 29.
Select te rm inal 27 output in par. 5-01 and
terminal 29 output in p ar. 5-02.
5-60 Termin al 27 Pulse Output Variable
Option:
*
No operation [0]
Function:
Select the variable for viewing on the
terminal 2 7 display.
This parameter cannot be adjusted while
the motor is running.
5-62 Pulse Output Maximum Frequency #27
Range:
0 - 32000 H z
*
5000Hz
Function:
Set the maximum frequency for terminal
27, corresp onding to the output variable
selected in par. 5-60.
This parameter cannot be adjusted while
the motor is running.
5-63 Termin al 29 Pulse Output Variable
Option:
*
No operation [0]
Function:
Select the variable for viewin g on the terminal
29 display. This parameter is available
for the FC 302 only.
This parameter cannot be adjusted while
the motor is running.
5-65 Pulse Output Maximum Frequency #29
Range:
0 - 32000 H z
*
5000Hz
Function:
Set the maximum frequency for terminal 29
corresponding to the output variable set in par. 5-63.
This parameter cannot be adjusted while
the motor is running.
5-66 Term in al X30/6 Pulse Output Var iable
Option:
*
No operation [0]
Function:
Select the variable for read-out on terminal
X30/6. This parameter cannot be adjusted
while the motor is running.
This parameter is active when option module MCB
101 is installed in the adjustable frequency drive.
5-68 Pulse O u tpu t Maximum Fre-
quency #X30/6
Option:
*
No operation [0]
Function:
Select the m aximum frequency on terminal
X30/6 referring to the outp ut variable in p ar.
5-66. This parameter cannot be adjusted
while the motor is running.
This parameter is active when option module MCB
101 is mounted in the adjustable frequency drive.
" 5-7* 24 V Encoder Input
Parameters for configuring the 24 V encode r.
Connect the 24 V encoder to terminal 12 (24 V
DC supply), terminal 32 (Channel A ), terminal 33
(Channel B), and terminal 20 (GND). The digital
inputs 32/33 are active for encoder inputs when
24
Vencoderis selected in par. 1-02 and par. 7-00.
The encoder used is a dual channel (A and B) 24
V type. Max input frequency: 110 kHz.
*
default setting ()display text []value for use in communication via serial communication port
199
MG.33.B
6.22 - V LT is a registered Danfoss trademark
