Danfoss FC 300 Design Guide

FC 300 Design Guide
How to Program
15-14 Samples Befor e Trigge r
Range:
0 - 100 N/A
*
50 N/A
Function:
Enter the percentage of all samples prior to a
trigger e vent which are to be retained in the log .
See also par. 1 5-12 and par. 15-13.
" 15-2* Historic Log
View up to 50 logged da ta items via the array
parameters in this parameter group. For all
parameters in the group, [0] is the most recent
data and [49] the old est data. Data is logged every
time an event occurs (not to be confused with SLC
events). Events in this context are de fined as a
change in one of the following areas:
1. Digital input
2. Digital outputs (not monitored in this SW release)
3. Warning word
4. Alarm word
5. Status word
6. Control word
7. Extended status word
Events are logged with value, and time stamp
in msec. The tim e interval between two events
depends on how often events occur (maximum once
every scan time). Data logging is continuous but if
an alarm occurs, the log is saved and the values can
be viewed on the display. This feature is useful, for
example w hen carrying out service following a trip.
View the historic log contained in this parameter via
the serial communication port or via the display.
15-20 Historic Log: Event
Array [50]
Range:
0-255
*
0
Function:
View the e vent type of the logged events.
15-21 Histo ric Log: Val ue
Array [50]
Range:
0 - 2147483647
*
0
Function:
View the value of the logged event. Interpret the
event values according to this table:
Digital input Decimal value. See par. 16-60
for d e scription after converting to
binary value.
Digital output (not
monitored in this
SW release)
Decimal value. See par. 16-66
for d e scription after converting to
binary value.
Warning word Decimal value. See par. 16-9 2 for
description.
Alarm word Decimal value. See par. 16-90 for
description.
Status word Decimal value. See par. 16-03
for d e scription after converting to
binary value.
Control word Decimal value. See par. 16-00 for
description.
Extended status
word
Decimal value. See par. 16-94 for
description.
15-22 Histori c Log: Time
Array [50]
Range:
0 - 2147483647
*
0
Function:
Viewthetimeatwhichtheloggedevent
occurred. Time is measured in ms since
frequency converter start.
" 15-3* Fault Log
Parameters in this group are array parameters,
where up to 10 fault logs can be viewed. [0]
is the most recent logged data, and [9] the
oldest. Error codes, values, and time stamp
can be viewed for all logged data.
15-30 Fault Log: Error Code
Array [10]
Range:
0-255
*
0
*
default setting ()display text []value for use in communication via serial communication port
242
MG.33.B
6.22 - V LT is a registered Danfoss trademark
