FC 300 Design Guide
FC 300 Selection
Max. terminal load (DC-13)
1)
on 4-6 (NC) (Inductive load) ............................................. 24 V DC, 0 .1 A
Min. terminal load on 1-3 (NC), 1-2 (NO), 4-6 (NC), 4-5 (NO) .................. 24 V DC 10 mA, 24 V AC 20 mA
Environment according to EN 60664-1 ................................... overvoltage category III/pollution degree 2
1) IEC 60947 part 4 and 5
The relay contacts are galvanically isolated from the rest of the circuit by reinforced isolation (PELV).
Control card, 10 V DC output:
Terminal number ......................................................................................................................... 50
Output voltage ............................................................................................................ 10.5 V ±0.5 V
Max. load ............................................................................................................................. 15 mA
The 10 V DC supply is galvonically isolated from the supply volta ge (PELV) and other high-voltage terminals.
Control c haracteristics:
Resolution of output frequency at 0 - 1000 Hz ........................................................................ 0.013 Hz
Repeat accuracy of Precise start/stop (terminals 18, 19) ............ FC 301: ±1ms/FC302: ±0.1msec
System response time (terminals 18, 19, 27, 29, 32, 33) ................... FC 301: 1 0 ms / FC 302: 2ms
Speed control range (open loop) ............................................................... 1:100 of synchronous speed
Speed control range (closed loop) ............................................................ 1:1000 of synchronous speed
Speed accuracy (open loop) ......................................................... 30 - 4000 rpm: Max. error of ±8 rpm
Speed accuracy (closed loop) .................................................... 0 - 6000 rpm: Max. error o f ±0.15 rpm
All control characteristics are based on a 4-pol e asynchronous motor
Surroundings:
Enclosure 10 HP [7.5 kW] ............................................................................................ IP 20, IP 55
Enclosure 14.75 H P [11 kW] ......................................................................................... IP 21, IP 55
Enclosure kit available 10 HP [7.5 kW] ........................................................... IP 21/TYPE 1/IP 4X top
Vibration test ............................................................................................................ 0.03 oz [1.0 g]
Max. relative humidity ................... 5% - 95% (IEC 721-3-3; Class 3K3 (non-condensing) during operation
Aggressive environment (IEC 721-3-3), uncoated ................................................................. class 3C2
Aggressive environment (IEC 721-3-3), coated .................................................................... class 3C3
Ambient temperature ............................... Max. 122°F [50°C] (24-hour average maximum 113°F [45°C])
Derating for high ambient temperature, see section on spec ial conditions
Minimum ambient temperature during full-scale operation ................................................... 32°F [0°C]
Minimum a mbient temperature at reduced performance ................................................... 14°F [-10°C]
Te mperature during storage/transport .......................................... -13° - +149/158°F [-25° - +65/70°C]
Maximum altitude above sea level ........................................................................... 3281 ft. [1000 m]
Derating for high altitude, see secti on on special conditions.
EMC standards, Emission ........................................................ EN 61800-3, EN 61000-6 -3/4 , EN 55011
EMC standards, Immunity ..................................................................... EN 61800-3, EN 61000-6-1/2,
EN 610 00-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
See section on special conditions
Control card performance:
Scan interval ........................................................................................ FC 3 01: 5 ms / FC 302: 1 ms
64
