Danfoss VACON 100 FLOW Series User Manual

Index
Parameter
Min
Max
Unit
Default
ID
Description
28 = Block Out.8
29 = Block Out.9
30 = Block Out.10
P3.13.3.4
Feedback 1 Mini-
mum
-200.00
200.00
%
0.00
336
P3.13.3.5
Feedback 1 Max-
imum
-200.00
200.00
%
100.00
337
P3.13.3.6
Feedback 2
Source Selection
0
20
0
335
See P3.13.3.3.
P3.13.3.7
Feedback 2 Mini-
mum
-200.00
200.00
%
0.00
338
See P3.13.3.4.
P3.13.3.8
Feedback 2 Max-
imum
-200.00
200.00
%
100.00
339
See P3.13.3.5.
1
The selection of the application with parameter P1.2 Application gives the default value. See the default values in
11.25 Default Values of Parame-
ters in the Different Applications.
Table 78: Feedforward Settings
Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.13.4.1
Feedforward Function
1
9
1
1059
See P3.13.3.1.
P3.13.4.2
Feedforward Function Gain
-1000
1000
%
100.0
1060
See P3.13.3.2.
P3.13.4.3
Feedforward 1 Source Selection
0
30
0
1061
See P3.13.3.3.
P3.13.4.4
Feedforward 1 Minimum
-200.00
200.00
%
0.00
1062
See P3.13.3.4.
P3.13.4.5
Feedforward 1 Maximum
-200.00
200.00
%
100.00
1063
See P3.13.3.5.
P3.13.4.6
Feedforward 2 Source Selection
0
30
0
1064
See P3.13.3.6.
P3.13.4.7
Feedforward 2 Min
-200.00
200.00
%
0.00
1065
See P3.13.3.7.
P3.13.4.8
Feedforward 2 Max
-200.00
200.00
%
100.00
1066
See P3.13.3.8.
Table 79: Sleep Function Settings
Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.13.5.1
SP1 Sleep Frequency
0.00
320.00
Hz
0.00
1016
0 = Not used
P3.13.5.2
SP1 Sleep Delay
0
3000
s
0
1017
0 = Not used
P3.13.5.3
SP1 Wake-up Level
-214748. 36
214748. 36
Varies
0.0000
1018
0 = Not used
P3.13.5.4
SP1 Wake-up Mode
0
1
0
1019
0 = Absolute level
1 = Relative setpoint
AB298035655957en-000201 / DPD01083116 | Danfoss A/S © 2023.08
Parameters Menu
VACON® 100 FLOW
Application Guide
