Table 82: Soft Fill Settings
Index
Parameter
Min
Max
Unit
Default
ID
Description
P3.13.8.1
Soft Fill Function
0
2
0
1094
0 = Disabled
1 = Enabled, Level
2 = Enabled, Timeout
P3.13.8.2
Soft Fill Frequency
0.00
P3.3.1.2
Hz
0
1055
P3.13.8.3
Soft Fill Level
-99999.9 9
99999.9 9
Varies
0.0000
1095
P3.13.8.4
Soft Fill Timeout
0
30000
s
0
1096
0 = No timeout, no fault triggering
P3.13.8.5
D Soft Fill Fault
0
3
2
748
0 = No action
1 = Alarm
2 = Fault (Stop according to stop mode)
3 = Fault (Stop by coasting)
Table 83: Input Pressure Supervision Parameters
Index
Parameter
Min
Max
Unit
De-
fault
ID
Description
P3.13.9.1
Enable Supervision
0
1
0
1685
0 = Disabled
1 = Enabled
P3.13.9.2
Supervision Signal
0
23
0
1686
0 = Analog input 1
1 = Analog input 2
2 = Analog input 3
3 = Analog input 4
4 = Analog input 5
5 = Analog input 6
6 = ProcessDataIn1 (0–100%)
7 = ProcessDataIn2 (0–100%)
8 = ProcessDataIn3 (0–100%)
9 = ProcessDataIn4 (0–100%)
10 = ProcessDataIn5 (0–100%)
11 = ProcessDataIn6 (0–100%)
12 = ProcessDataIn7 (0–100%)
13 = ProcessDataIn8 (0–100%)
14 = Block Out.1
15 = Block Out.2
16 = Block Out.3
17 = Block Out.4
18 = Block Out.5
19 = Block Out.6
20 = Block Out.7
21 = Block Out.8
22 = Block Out.9
23 = Block Out.10
P3.13.9.3
Supervision Unit
Selection
0
9
Varies
3
1687
1 = %
2 = mbar
AB298035655957en-000201 / DPD01083118 | Danfoss A/S © 2023.08
Parameters Menu
VACON® 100 FLOW
Application Guide
