Getting Started

18 Gryphon™ I GD4100/GM4100

Figure 2. RS-232 Connection

Keyboard Wedge Connection

The Keyboard Wedge cable has a ‘Y’ connection from the reader. Connect the female to the

male end from the keyboard and the remaining end at the keyboard port at the terminal/PC.

Reference Figure 3.

Figure 3. Keyboard Wedge Interface connection

USB Connection

Connect the reader to a USB port on the terminal/PC using the correct USB cable for the

interface type you ordered. Reference Figure 4.

Default Chapter3
