Chapter 3 Electrical Wiring｜VP3000
131
Frame K2
Applicable models: VFD460VP43BSTCA–VFD485VP43BSTCA, VFD460VP43BFTCA–VFD485VP43BFTCA
1. Loosen the RFI jumper (fasten the M4 screws back to the original place).
Screw torque: 8–10 kg-cm / (6.9–8.7 lb-in.) / (0.78–0.98 Nm)
Figure 3-94
2. Place the RFI jumper and fasten back the screws.
Screw torque: 8–10 kg-cm / (6.9–8.7 lb-in) / (0.78–0.98 Nm)
Figure 3-95
