Electrical Specification
Power Supply Voltage
5 V
DC
(supplied by the AC motor drive)
Insulation Voltage
500 V
DC
Power Consumption
1 W
Weight
28 g
Table 10-8
Environment
Noise Immunity
ESD (IEC 61800-5-1, IEC 61000-4-2)
EFT (IEC 61800-5-1, IEC 61000-4-4)
Surge Test (IEC 61800-5-1, IEC 61000-4-5)
Conducted Susceptibility Test (IEC 61800-5-1, IEC 61000-4-6)
Operation / Storage
Operation: -10–50ºC (temperature), 90% (humidity)
Storage: -25–70ºC (temperature), 95% (humidity)
Shock / Vibration
Resistance
International standards: IEC61131-2, IEC60068-2-6 (TEST Fc) / IEC61131-2
& IEC60068-2-27 (TEST Ea)
Table 10-9
⚫ Installation
PROFIBUS DP Connector
PIN
PIN Name
Definition
1
6
5
9
Figure 10-29
1
-
Not defined
2
-
Not defined
3
Rxd/Txd-P
Sending/ receiving data P (B)
4
-
Not defined
5
DGND
Data reference ground
6
VP
Power voltage – positive
7
-
Not defined
8
Rxd/Txd-N
Sending/ receiving data N (A)
9
-
Not defined
Table 10-10
⚫ LED Indicator & Troubleshooting
There are 2 LED indicators on CMC-PD01: POWER LED and NET LED. POWER LED
displays the status of the working power. NET LED displays the connection status of the
communication.
POWER LED
LED Status
Indication
Corrective Action
Green light
ON
Power spply is in normal status
--
OFF
No power
Check if the connection between CMC-PD01 and
AC motor drive is normal.
Table 10-11
