DGSHAPE DE-3 - Main Specifications

Main Specications
DE-3
Workpiece table size Width × Depth: 305 × 230 mm (12.0 × 9.1 in.)
X, Y, and Z operation
strokes
X, Y, Z: 305 × 230 × 40 mm (12.0 × 9.1 × 1.6 in.)
X-, Y-, and Z-axis drive
system
Stepping motor, 3-axis simultaneous control
Operating speed X and Y axes: 0.1 to 60 mm/sec. (0.004 to 2.4 in./sec.)
Z axis: 0.1 to 30 mm/sec. (0.004 to 1.2 in./sec.)
Software resolution 0.01 mm/step (0.00039 in./step)
Spindle motor Brushless DC motor
Spindle rotating speed 5,000 to 20,000 rpm
Tool chuck Cutter holder, collet method
Loadable workpiece
thickness
Maximum 40 mm (1.6 in.) (38 mm (1.5 in.) when nose unit is used)
Interface
USB
Ethernet (10BASE-T/100BASE-TX, automatic switching)
Control command sets RML-1
Power
supply
Voltage and
frequency
100 VAC ± 10%, 50/60 Hz (overvoltage category: II, IEC 60664-1)
Current rating 1.0 A
Power consumption 80 W
Operating noise During operation: 63 dB (A) or less (when not cutting), during standby: 40 dB
(A) or less
External dimensions Width × Depth × Height: 616 × 587 × 390 mm (24.3 × 23.1 × 15.4 in.)
Weight 35 kg (77.2 lb.)
Installation environment Indoor use at altitudes up to 2,000 m (6,562 feet) or less
Temperature: 5 to 40°C (41 to 104°F), Humidity: 35 to 80% (no condensation)
Ambient pollution degree: 2 (as specied by IEC 60664-1)
Included items Power cord, power plug adapter, USB cable, nose unit (nose cone resin/
metal), nose unit retainer (retaining screw, spring), spare tool retaining screw
(for the cutter holder), character cutter (ø3.175 mm (0.125 in.)), solid collet
(ø3.175 mm (0.125 in.)), wrench, hexagonal wrench, hexagonal screwdriver,
adhesive sheet, vacuum adapter, DGSHAPE Software Package CD, and
Setup Guide
Machine Specications
156
Chapter 6 Appendix
