F
Press [ENTER/PAUSE].
The working time of the spindle is reset.
Replacing the Resin Nose Cone
The resin nose cone is a consumable part. It wears out as you continue to perform engraving. Replace it at the
appropriate time.
Checking the Replacement Time
The resin nose cone should be replaced when it becomes worn to the protrusion as shown in the gure. Replace
the nose cone with a new one.
Protrusion
Replacement
Procedure
A
Loosen the retaining screw.
To prevent the retaining screw from being lost, just loosen the retaining screw enough to remove the
nose unit, leave the retaining screw attached.
Retaining screw
Nose unit
Replacing Consumable Parts
73
Chapter 4 Maintenance
