Storing the Cutter
For repeated use while keeping the amount of extension of the cutter tip constant, we recommend that you
remove the cutter holder and cutter from the spindle unit without separating them from one another once you
have determined the amount of extension. Storing the assembly without changing the position of the cutter
holder eliminates the need to determine the amount of cutter extension each time you use it.
* This method cannot be used with the ø4.36 mm (0.17 in.) solid collet and end mill.
Storage Methods for ø3.175 mm (0.125 in.) Character Cutter/Parallel Cutter
Remove the cutter from the spindle unit together with the
cutter holder.
Store without changing the position of the
cutter holder.
Storage Method for the Diamond Scraper
Remove the entire diamond scraper from the spindle unit. Store without changing the position of the
cutter holder.
Daily Care
70
Chapter 4 Maintenance
