Spindle Run-in (Warm-up)
Perform spindle run-in (warm-up) to stabilize the rotation of the spindle.
Procedure
A
Close the front cover.
B
Press [ENTER/PAUSE].
C
On the main screen, press [SPINDLE].
The cursor moves to [S], and the spindle rotating speed can be changed.
SPINDLE
ON/OFF
D
Turn the [Dial] on the handy panel until the spindle rotating speed reaches "5000 rpm."
Slow
Fast
X 50.00mm
Y 30.00mm
Z 20.00mm S 5000rpm
012345678901234567 READY
Spindle rotating speed
CAUTION
The spindle rotating speed can only be changed while the cursor is displayed at the [S] position.
X 50.00mm
Y 30.00mm
Z 20.00mm S 5000rpm
012345678901234567 READY
If no operations are performed for a certain amount of time and the cursor disappears, press [SPINDLE] several
times to move the cursor to [S], and then operate the [Dial].
When the Machine Has Not Been Used for a Prolonged Period
80
Chapter 4 Maintenance
