DGSHAPE DE-3 - Step 2: Creating a Shape

Step 2: Creating a Shape
Draw a rectangle.
Congraturations
30 mm
(1.2 in.)
7 mm
(0.3 in.)
60 mm (2.4 in.)
5 mm
(0.2 in.)
Procedure
A
Click .
B
Click the start point at any location, and then drag it to the end point.
Start point
End point
Creating Engraving Data
30
Chapter 3 Basic Engraving Methods
