DGSHAPE DE-3 - Maintenance Precautions

F
Turn the [Dial] and set the avoidance height.
For the setting value, set the distance from Z user origin.
AUTO Z SETTING
UP 5.00mm
012345678901234567 READY
Z user origin
The avoidance
height you have set
Workpiece
If the dierence in level is above the origin, specify the setting value
that exceeds the dierence in level.
G
Press [ENTER/PAUSE] to conrm.
H
Hold down and press [MENU/TOP].
The main screen appears again.
X 15.00mm
Y 23.00mm
Z 0.00mm S 5000rpm
012345678901234567 READY
Setting Range
0 mm to 40 mm (1.6 in.) (in 0.1 mm [3.9 mil] steps)
Other Basic Operations
65
Chapter 3 Basic Engraving Methods
