6 Press ASSIGN to confirm, or ESC/CANCEL to
exit Input Assignment mode. The ASSIGN and
ESC/CANCEL buttons will stop flashing to indi-
cate that you have left the Assignment mode.
Your routing assignments will not be saved if
you press ESC/CANCEL without first confirm-
ing your selections by pressing either the master
ASSIGN button or the flashing button directly
below the data encoder knob on each selected
track.
Assigning Sends to a Single Track
in Pan/Send Mode
When a track’s PAN/SEND button is pressed,
Control 24 enters Pan/Send mode, and the
track’s panning, sends, and sends panning in-
formation is spread across the scribble strips.
Track and Send Names
The track name appears in the Channel Bar Dis-
play. The encoder knob on the far left is the pan
control, and the encoder ring displays approxi-
mate panning position.
Send Information
Information for the five sends is spread across
the scribble strips. Each send name is abbrevi-
ated to fit into one strip.
The encoder under the next strip to the right
contains the send destination information and
controls the send level. The next scribble strip to
the right contains the send’s panning informa-
tion.
When you have confirmed a send assignment,
the SWITCH ACTIVE LEDs should light up be-
low the encoder buttons that correspond to that
send’s destination and the panning information
should show up in the scribble strips.
Send Level and Mute Controls
The encoder knob below the send destination
strip functions as the send level control. The re-
spective scribble strip briefly displays the send
level information and then reverts back to the
send destination information.
The corresponding encoder button below this
knob functions as a Send Mute toggle control.
The respective scribble strip briefly displays
“Mute” when muted and then reverts back to
the send destination information.
When muted, this encoder button’s LED will
light.
Send Panning and Pre/Post Toggle
Control
The next scribble strip, to the right of the send
destination indicator, displays panning infor-
mation for the send. The encoder knob below
the scribble strip adjusts panning.
The associated encoder button serves as a pre- or
post-fader toggle for the send (lit if pre-fader).
Routing assignments cannot be made while
the Pro Tools Transport is engaged.
When scrolling through input, output, or in-
sert options, the currently selected assign-
ments will be indicated by a “>“symbol in
front of the assignment name.
