Dräger Infinity M300 series - Infinity M300; M300+ Front of the Device

System overview
52 Instructions for use – Infinity
®
M300 and M300+ series – VG3.0
Infinity M300+
M300+ front of the device
The following figure shows the M300+ front of the device.
NOTE
Figures of products and screen content in this document may differ from the actual products depending
on configuration and design.
NOTE
The battery retainer secures the battery to the M300+. The battery retainer should always be in place
when using the device.
- +
Speaker for acoustic alarm signal
Status LED
Battery charge symbol
Keypad
Swappable battery pack
Battery release tabs
(one on each side)
Battery retainer (see Note below)
