7. Push button
By means of the push button it is possible to control the clamps and to
start the sewing operation. According to the adjustment in the service
menu (see service instructions) the function is different.
1. Adjustment
–
Key 1: The clamps are opened or closed respectively.
–
Key 2: The sewing operation starts when the clamps are closed.
2. Adjustment
–
Key 1: The clamps are opened or closed respectively.
–
Key 2: If the clamps are not lowered, they will be lowered now. The
sewing operation starts.
8. Setting the cloth stops
Caution: Danger of injury !
Adjust the c loth stops only when the automatic buttonholer is
switched off!
–
Place the sewing material until it touches the cloth stops 2 on both
sides (right and left).
–
Loosen the screws 1 on the right and left.
–
Adjust the s ewing position by moving the cloth stops 2.
–
Tighten the screws 1 again.
18
1
1
2
