Menu item Description
143 Eyelet inclination: the buttonhole eye can be slightly inclined to the left or to the right.
150 Throw w idth: the mechanically regulated throw width (stitch w idth) can
be enlarged up to 1 mm and reduced up to 0.5mm.
160 Cutting adjustments
161 Cutting mode: depending on the sewing equipment, the buttonhole c ut can be
set either after sewing (1), before (2), or not at all (0).
0 = no cutting
1 = cutting after sewing (CA)
2 = cutting before sewing (CB)
162 Cutting area: the internal distance between the two lips of the buttonhole
is meant by cutting area.
163 Cutting correction in x-direction: the k nife position can be displaced to the right/left
within the buttonhole.
164 Cutting correction in y-direction: the knife position can be displaced to the rear/front
within the buttonhole.
165 Correction of cutting pressure: automatic adjustment (4 steps) of the cutting force
of the buttonhole k nife depending on the buttonhole length.
-buttonhole length (eyelets) up to 14 mm 2 steps
-buttonhole length from 15 mm to 30 mm 3 steps
-buttonhole length from 31 mm 4 steps
The preset c utting force can be increased/decreased in the above menu item,
depending on the buttonhole length.
170 Taper tack adjustments
171 Taper tack length: the taper tack length can be set from 2 mm to 36 mm, depending
on the equipment and the buttonhole length.
172 Throw w idth in the taper tack: the throw width (stitch width) for the whole buttonhole
(see menu item 150) can be r educed in the taper tack.
173 Overlapping in the taper tack: overlapping of the buttonhole seams.
174 Height of the tack slant: the taper length in the tack is adjustable.
180 Cross tack adjustments
181 Cross tack length: the overall length of the cross tack.
182 Stitch length in the cross tack: distance from stitch to stitch within the cross
tack (from 0,5 mm to 2 mm).
183 Throw w idth in the cross tack: the mechanically regulated throw width
(stitch width) can be enlarged/reduced.
184 x-position of the cross tack: the whole cross tack can be shifted to the right/left.
185 Seam extension in the cross tack: the overlapping of the buttonhole seams
with the cross tack is meant by seam extension in the cross tack.
