DURKOPP ADLER 867 Service Manual

Technical data
152 Service Instructions 867 - 04.0 - 10/2019
2-needle long arm machines with integrated motor (-M)
26.4 Requirements for fault-free operation
Compressed air quality must conform to ISO 8573-1: 2010 [7:4:4].
Subclasses: 867-
-290020-70-M ECO -290040-70-M ECO
-290122-70-M -290322-70-M -290342-70-M -290142-70-M
-290342-100-M
(Long arm)
Stitch length
0-6
Stroke 1-3 3000 3000 3000 3000 3000 3000 2500
Stroke 4 2800 2800 2800 2800 2800 2800 2300
Stroke 5 2000 2000 2000 2000 2000 2000 2000
Stroke 6-9 1800 1800 1800 1800 1800 1800 1800
Stitch length
6-9
Stroke 1-3 3000 3000 3000 3000 3000 3000 2500
Stroke 4 2800 2800 2800 2800 2800 2800 2800
Stroke 5 2000 2000 2000 2000 2000 2000 2000
Stroke 6-9 1800 1800 1800 1800 1800 1800 1800
Stitch length
9-12
Stroke 1-5 2000 2000 2000 2000 2000 2000 2000
Stroke 6-9 1800 1800 1800 1800 1800 1800 1800

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
