3.3.3 Assembling and disassembling the head cover
Fig. 3: Assembling and disassembling the head cover
Disassembling the head cover
To disassemble the head cover:
1. Loosen the screws (1).
2. Disassemble the head cover (2).
Assemble the head cover
To assemble the head cover:
1. Assemble the head cover (2).
2. Tighten the screws (1).
(1) - Screws (2) - Head cover
