Feed dog
Service Instructions 867 - 04.0 - 10/2019 35
8Feed dog
The position and the movement of the feed dog and needle bar have to
be coordinated such that the needle pierces exactly in the center of
the needle hole of the feed dog.
Order
First, check the following setting:
• Needle bar linkage( p. 45)
8.1 Adjusting the feed dog position
Proper setting
The feed dog is exactly in the center of the throat plate cutout, both
sideways and in the sewing direction.
If the stitch length is 0, the needle pierces exactly in the center of
the needle hole.
Various settings can be made depending on how far the position of
the feed dog differs from the correct setting:
• For minimal deviations, it suffices to move the feed dog on the carrier
( p. 36)
• If this is not sufficient, move the entire feed dog carrier on the pusher
shaft ( p. 37)
WARNING
Risk of injury from moving parts!
Crushing possible.
Switch off the machine before you set the feed dog
position.
