Machines with integrated motor
Service Instructions 867 - 04.0 - 10/2019 97
19.3.5 Locking the machine in place
Fig. 82: Locking the machine in place (1)
To lock the machine in place:
1. Lock the machine in place using the locking peg (1) (Ø 3 mm).
The needle is in the top dead center position.
19.3.6 Assembling the handwheel flange
Fig. 83: Assembling the handwheel flange
(1) - Locking peg
(1) - Handwheel flange
(2) - Marking
(3) - Marking
(4) - Threaded pins
