DURKOPP ADLER 867 Service Manual

Maintenance
Service Instructions 867 - 04.0 - 10/2019 123
22.4.2 Checking the toothed belt
The condition of the toothed belt must be checked once a month.
Important
A damaged toothed belt must be replaced immediately.
Proper setting
The toothed belt exhibits no cracks or fragile areas.
When pressed with a finger, the toothed belt must yield no more than
10 mm.
22.5 Parts list
A parts list can be ordered from Dürkopp Adler. Or visit our website for
further information at:
www.duerkopp-adler.com
WARNING
Risk of injury from moving parts!
Crushing possible.
Switch off the machine before checking the toothed
belt.

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
